Overview Company Profile Founded in 2021, Guangdong Fractional Dimension Wireless Technology Co., Ltd. Is a high-tech en
Overview
Company Profile
The company has a reasonable talent structure, with the professor of Guangdong University of Technology and the person in charge of electronics and science and technology as the company's R & D leader. The company has many doctors from South China University of Technology and China University of Electronic Science and Technology as the main technical backbone of the R & D department, as well as many R & D engineers with senior and middle-level technical titles. The company focuses on the research direction of "microwave and millimeter wave dual-band dual-polarization and phased array antenna", and has developed related products and solutions. The company also employs industry experts as consultants to closely track the development characteristics of the new generation of wireless communication technology and industry, constantly optimize the company's product line, and solve user needs. Let them get the best service and the best return on investment.
Since its establishment, the company has always adhered to the principle of talent-oriented and honest operation, gathered elites from the industry, combined foreign advanced information technology, management methods and enterprise experience with the specific reality of domestic enterprises, provided comprehensive solutions for enterprises, helped enterprises improve their management level and production ability, and made enterprises always adhere to competitiveness in the fierce market competition. To achieve rapid and stable development of enterprises.
Basic Info.
| Model NO. | FSW-QFD0838C01 |
| Material | Al |
| Directionality | Directional Antenna |
| VSWR | <1.5 |
| Base Antenna | High Gain Antenna |
| Nature of Operation | Receiving Antenna |
| Sturcture Form | Wire Antenna |
| Dimensionality | Two-Dimensional Antenna |
| Operating Temperature Rang | -40ºC/+60ºC |
| Rated Wind Velocity | 60m/S |
| Input Impedance | 50Ω |
| Max Input Power | 50W |
| Specification | 410*210*64 |
| Trademark | FSW |
| Origin | Foshan |
| Production Capacity | 50000 |
Product Description
| Electrical indicators | |||
| Frequency range (MHz) | 806~960 | 1710~2700 | 3300~3800 |
| Polarization mode | Vertical | ||
| Gain (dBi) | 9±1 | 9±1 | 9±1 |
| Horizontal half power lobe width (°) | 80±15 | ||
| Vertical half power lobe width (°) | 60 | 55 | 50 |
| Front to back ratio (dB) | ≥15 | ||
| Input Impedance (Ω) | 50 | ||
| Voltage standing wave ratio | ≤1.5 | ||
| Third-order passive intermodulation (2x33dBm carrier) | ≤-140 dBc | ||
| Maximum power (W) | 50 | ||
| Lightning protection | DC grounding | ||
| Mechanical indicators | |||
| Connector type | N-type female or user specified | ||
| Lead length (cm) | 20 or user specified | ||
| Connector location | Bottom | ||
| Antenna size (mm) | Customizable | ||
| Package size (mm) | Customizable | ||
| Antenna weight (kg) | 1.0 ± 0.1 (including clip code) | ||
| Radome material | ABS | ||
| Radome color | White | ||
| Operating temperature (ºC) | -40~60 | ||
| Application scenario | Outdoor | ||
| Mechanically adjustable tilt angle (°) | 0 ° or 42 ° | ||
| Limiting wind speed (m/s) | 40 | ||
| Diameter of holding pole (mm) | Φ25-Φ50 | ||
Founded in 2021, Guangdong Fractional Dimension Wireless Technology Co., Ltd. Is a high-tech enterprise focusing on the research, development, production and sales of new generation information technology products and solutions. The company has strong technology and R & D strength, and is the innovation and entrepreneurship team of "Blue Sea Talent Plan" in Nanhai District of Foshan City in 2020.
The company has a reasonable talent structure, with the professor of Guangdong University of Technology and the person in charge of electronics and science and technology as the company's R & D leader. The company has many doctors from South China University of Technology and China University of Electronic Science and Technology as the main technical backbone of the R & D department, as well as many R & D engineers with senior and middle-level technical titles. The company focuses on the research direction of "microwave and millimeter wave dual-band dual-polarization and phased array antenna", and has developed related products and solutions. The company also employs industry experts as consultants to closely track the development characteristics of the new generation of wireless communication technology and industry, constantly optimize the company's product line, and solve user needs. Let them get the best service and the best return on investment.
Since its establishment, the company has always adhered to the principle of talent-oriented and honest operation, gathered elites from the industry, combined foreign advanced information technology, management methods and enterprise experience with the specific reality of domestic enterprises, provided comprehensive solutions for enterprises, helped enterprises improve their management level and production ability, and made enterprises always adhere to competitiveness in the fierce market competition. To achieve rapid and stable development of enterprises.
